Mini 3D Subsurface Laser Engraving Machine / 3D Laser Engraving System for Crystal

I want to publish your team. As an engineer with 10 years of practice (cnc and co2 lasers), I can say you are doing good equipment. Upgrade your software, and can compete with the Germans.

—— Serz

I'm Online Chat Now

Mini 3D Subsurface Laser Engraving Machine / 3D Laser Engraving System for Crystal

China Mini 3D Subsurface Laser Engraving Machine / 3D Laser Engraving System for Crystal supplier
Mini 3D Subsurface Laser Engraving Machine / 3D Laser Engraving System for Crystal supplier Mini 3D Subsurface Laser Engraving Machine / 3D Laser Engraving System for Crystal supplier Mini 3D Subsurface Laser Engraving Machine / 3D Laser Engraving System for Crystal supplier

Large Image :  Mini 3D Subsurface Laser Engraving Machine / 3D Laser Engraving System for Crystal

Product Details:

Place of Origin: China
Certification: CE
Model Number: STNDP-801AB1

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negociable
Packaging Details: Standard plywood package
Payment Terms: T/T, , L/C, Western Union, MoneyGram
Supply Ability: 1000 sets per year
Detailed Product Description
Warranty: 2 Years Laser Box: Diode Dump 532nm
Material: Glass And Crystals Size: 120*200*100mm
High Light:

3d laser subsurface engraving machine

,

subsurface laser engraving machine

Mini 3D Crystal Laser Inner Engraving Machine / 3D Crystal Engraving Machine



STNDP-801AB1 is a special designed for the start level business model, besides the goods 3d engraving ability, as a portable machine,it also with the good engraving quality for 2d images, and with mass production ability for small crystals, which is a muti-function machine.It have advantages of compact size,light weight and carrying easily. Strictly accordance with CE and FDA Standards, the design and production ensure the safety and stability of the using process .The fast engraving speed can guarantee that consumers just wait a few minutes and will get the customized crystal gifts.



Model STNDP-801AB1
Max engraving size (mm)

120*200*100

(4.7''x7.8''x3.9'')

Laser Type Diode pumped Nd:YAG, 532nm green laser; 4000Hz
Pulse width ≤6ns
Engraving Speed Maximum: 4,000 points/s; Normal: 3,500 points/s,200,000 dots/min
Diameter of a point 20-40μm
Repeated location accuracy <10μm
Continuous work time >24 hours
Cooling air
Diode laser module life >12000 hours
Power consumption <800W
Electrical connection Single 220V or 120V (+/-10%); 50Hz or 60Hz
Typical case for normal engraving speed Crystal size:50*80*50mm pattern:300000 dots,Engraving time:<2minutes
Warranty 2 years(1 year for diode)
File Format JPG,BMP,,DWG,DXF,3DS etc.
Operation demands Room temperature:5--35℃ ;room humidity :<70% no condensation
Weight 70Kg
Machine Size (L*W*H)(mm) 460*560*730
Package Size(L*W*H)(mm) 905*640*915



Application:

Integrated with high-peak power laser system which developed by STN Laser, For this special size 3d laser engraving machine, which is special designed for the start level customers.Besides the nice 3d engraving service, it also have the ability to engrave middle size of 2d crystals,such as crystal frames,this is very popular for personal 2d photo engraving services



Our Services:

Optional accessories we can offer

A. Professional 3d camera

B. 2d to 3d conversion software

C. Blank crystals

D. Led Bases



Services offered

A. 2 year warranty for whole machine

B. 24 hours online services

C. softwares updating lifetime for free



Training solutions

A. Free on-line training, English training supported

B. Free training in our factory for checking and machine and full training freely 3-5 days full training in our factory freely

C. In site training can be offered if needed.



Our Package and Tranformation:

Mini 3D Subsurface Laser Engraving Machine / 3D Laser Engraving System for Crystal

Mini 3D Subsurface Laser Engraving Machine / 3D Laser Engraving System for Crystal

Mini 3D Subsurface Laser Engraving Machine / 3D Laser Engraving System for Crystal
